The sleeve of the Ø10 anchor is one-piece, while the sleeves of the Ø12 and Ø14 anchors consist of
a 100 mm long expansion segment and 40 mm long segments that extend the part intended for the
thickness of the element to be fixed.
- Sleeve made of material resistant to shocks and low temperatures.
- Large expansion force guarantees high load capacities
- Sleeve flange - conical-flat for Ø10, flat widened for Ø12 and Ø14
- Screw with ceiling or straight hook made of ordinary carbon steel S235JRG2 according to PN-EN ISO 10025-1:200
